Description
The unique custom design sensor offers 180/360 images at capture speeds up to 20 Million Images/second at full resolution. In line with high-speed video cameras the Aurora can be Frame synchronised with an external device such as another Aurora or laser.
The Aurora can also be recording prior to the event and triggered before, during or after the event.
Aurora255K | Aurora5M | Aurora10M | Aurora20M | |
Frame Rate (fps) | Up to 255Kfps | Up to 5Mfps | Up to 10Mfps | Up to 20Mfps |
Exposure Time | 1 μs | 100 ns | 50 ns | 25 ns |
Trigger Mode | Start, End and Center | |||
Main Features:
- Up to 20 Million images/second capture speeds
- Adjustable exposure down to 25ns
- 924(W) x 768(H)
- 180/360 frames at all speeds
- Pre & Post event triggering
- External synchronisation
- Nikon lens mount fitting
- Gigabit ethernet communications
- Compact, rugged design
Applications:
- Combustion research
- Biological/Microscopic
- Ballistics
- Mechanics
- Cavitation
- Materials research
- Aerospace
- Digital Image Correlation
- PIV
